Automatic Weld Size Gauge

Name: Automatic Weld Size Gauge
Brand: CALTECH ENGINEERING SERVICES
Price: 50 INR
Availability: InStock

Price 50 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Automatic Weld Size Gauge Specification

Case
Plastic/Metal

Display
Analog Scale

Outer Size
150mm

Measuring Range
1mm to 25mm

Sensor Type
Manual (Non-Electronic)

Material
Stainless Steel / Hardened Steel

Grade
Industrial

Application
Measuring Weld Size and Throat Thickness

Accuracy
0.5 mm

Finish
Satin/Matte

Scale Type
Etched graduations

Packing
Supplied in plastic case or pouch

Corrosion Resistance
Yes

Weight
Approx. 50 grams

Usage
Universal for butt, fillet, and reinforcement welds

Compliance
Meets international welding inspection standards

Automatic Weld Size Gauge Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
500 Units Per Day

Delivery Time
1 Days

Main Export Market(s)
Western Europe, Asia, Australia, North America, Eastern Europe, Middle East, Central America, South America, Africa

Main Domestic Market
All India

About Automatic Weld Size Gauge

For Accurate Calibration of Butt and Fillet Type Welds / GAL Welding Gauges

With the new improved GAL Gauge A.W.S. Gauge shown above it is possible to meet specifications of butt and fillet type welds. New designed instrument is pocket sized and easy to operate, new feature includes thumb screw which replaces old hard to perate rivet type.

Diagrams at left illustrate the ease with which welders and inspectors may accurately check sizes of convex or concave fillets as well as butt weld reinforcements.

The convexity and concavity sizes have automatically been predetermined in accordance with American Welding Society D1.1Paragraph 3.6.

GAL Welding Inspection Gauge is precision built of stainless steel with dimensional readings chemically etched and filled for easier reading

GAL Gage Co manufactured high performance welding inspection gauges are highly popular and recommended by welding inspectors..

Precision Measuring for All Weld Types

This automatic weld size gauge is purpose-built for a wide range of welding applications, precisely measuring both weld size and throat thickness for butt, fillet, and reinforcement joints. Its etched graduations ensure measurements remain clear and lasting, while the universal design caters to numerous welding tasks.

Durable, Corrosion-Resistant Construction

The gauge is manufactured from top-grade stainless or hardened steel and finished in a refined satin/matte style. Enhanced corrosion resistance ensures longevity and reliable performance, even in demanding industrial settings. The robust construction supports consistent accuracy, making it suitable for daily inspection use.

User-Friendly and Highly Portable

Weighing just 50 grams, this manual, analog weld gauge is extremely easy to handle and transport. Supplied in either a sturdy plastic or metal case, it is simple to keep protected and organized. Its compact outer size (150mm) allows for efficient use in tight inspection spaces and convenient portability.

FAQs of Automatic Weld Size Gauge:

Q: How is the Automatic Weld Size Gauge used to measure welds?

A: To measure welds, place the gauge against the weld joint, align the reference point, and read the etched graduations on the analog scale. It can be used manually to accurately measure weld size and throat thickness for butt, fillet, and reinforcement welds within the 1mm to 25mm range.

Q: What are the benefits of a satin/matte finish on this weld gauge?

A: The satin/matte finish reduces glare and enhances visibility of etched graduations, making it easier to read measurements in various lighting conditions. Additionally, it provides a professional appearance and added resistance against scratches during regular use.

Q: When should this gauge be used during the welding process?

A: This gauge is typically used during inspection phasesbefore, during, and after the welding processto ensure that welds conform to specified sizes and meet international inspection standards. It is vital for quality assurance in both field and workshop settings.

Q: Where can this weld gauge be applied?

A: The weld size gauge can be utilized in a wide variety of industrial environments, such as construction sites, fabrication shops, maintenance departments, and inspection services. Its universal functionality makes it suitable for dealers, exporters, manufacturers, and service providers across India.

Q: What makes this gauge compliant with international welding standards?

A: The gauge is precisely manufactured with high-quality materials, features accurate etched gradations, and is designed to meet the dimensions and tolerances stipulated by international welding inspection standards, ensuring reliable and recognized measurement results worldwide.

Q: How does manual operation benefit the user compared to electronic types?

A: Manual operation ensures that the gauge is simple to use, does not require batteries or electronic calibration, and remains reliable across different environments. Its analog design eliminates the risk of malfunctions due to electronic failure or harsh conditions.
