Testex Tape Press-O-Film

Name: Testex Tape Press-O-Film
Brand: CALTECH ENGINEERING SERVICES
Price: 50 INR
Availability: InStock

Price 50 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Testex Tape Press-O-Film Specification

Resolution
1 m

Measurement Range
20 to 115 m (depends on tape grade)

Capacity
Single-use strips in roll packaging

Protection
N/A (manual device)

Pressure Range
Atmospheric

Humidity %
Up to 85% RH

Temperature Range
5C to 50C operating environment

Application Media
Surface profile measurement on blasted steel surfaces

Equipment Type
Surface Profile Replication Tape

Diameter
12 mm (replica tape region)

Sensor Type
Manual compression film

Material
Plastic (mylar film with compressible foam)

Power Supply
Not applicable (manual device)

Accuracy
10% of reading

Display Type
None (manual optical measurement)

Range
20 - 64 m, 38 - 115 m (depends on grade)

Testex Tape Press-O-Film Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
500 Units Per Day

Delivery Time
1 Days

Main Export Market(s)
South America, Western Europe, North America, Eastern Europe, Middle East, Central America, Asia, Australia, Africa

Main Domestic Market
All India

About Testex Tape Press-O-Film

Testex Tape Press-O-Film

Caltech india offers testex tape. Testex Tape is popularly called as Press-O-Film. Testex Tape press-o-film provides surface profile of a basted cleaned surface. Press O Film Replica Tape can produce virtually exact replicas of the blasted surface profile, which can be measured, using a snap gauge or testex profile gauge. Testex tape offers a simple and very accurate method of measuring blasted profiles of blasted surface. We are textex tape distributors in India.

Testex Tapes Press O Film consists of layer of crushable plastic microfoam coated onto a polyster film of highly uniform thickness. Supplied with burnishing tool and testex tape instructions. Low cost way for surface replication and measurement to measure profile

Surface profile gauge or testex tape press-o-film can test surface roughness. Most commonly used testex tape / press o films are popular as it can give permanent record of the surfaces as a proof of testing done on prepared surface.

Accurate Surface Profile Measurement

Testex Tape Press-O-Film enables reliable measurement of blasted steel surface profiles by producing a physical replica. Inspectors can easily compress the tape and measure the resulting profile with a standard micrometer, ensuring consistent results across multiple applications. Two grades are available to cover a broad measurement range from 20 to 115 m.

Simple Application & Manual Operation

The tape features a gentle, low-tack adhesive that secures the strip during measurement but leaves no residue. Its design allows for straightforward compression and removal, making it ideal for single-use tasks in quality control routines. No power supply or display is required; only a compatible micrometer with flat anvils is necessary.

Durable Packaging and Reliable Performance

Each roll is individually packed and boxed to maintain tape integrity during storage. To achieve optimal shelf life of up to 12 months, store the tape in sealed packaging, away from sunlight and high humidity. Whether by dealer, supplier, or manufacturer, users benefit from robust, easy-to-handle strips suited for various workplace environments.

FAQs of Testex Tape Press-O-Film:

Q: How is Testex Tape Press-O-Film used to measure surface profiles?

A: To measure the profile of a blasted steel surface, press a strip of the replica tape onto the surface, compress it with consistent finger pressure, then remove and measure the replicas thickness using a flat anvil micrometer. This process provides a direct, manual reading of the surface profile height.

Q: What surfaces and applications are suitable for Testex Tape Press-O-Film?

A: The tape is specifically designed for measuring the surface profile of abrasive-blasted steel prior to painting or coating. It is commonly employed by surface inspectors and QA/QC professionals to ensure adequate preparation for bonding and coating tasks.

Q: When should the tape be replaced during a testing sequence?

A: Each strip is intended for single-use only. Replace the tape after one measurement to ensure accurate readings and prevent errors from repeated application or surface contamination.

Q: Where should Testex Tape Press-O-Film be stored to maintain shelf life?

A: Store the tape in its original sealed packaging, in a cool, dry area. To preserve the 12-month shelf life, avoid exposure to direct sunlight and high humidity (keep below 85% RH).

Q: What type of micrometer is needed for accurate measurement?

A: A digital or analogue micrometer with flat anvils is required. The tape replica is measured for thickness after application, and flat anvils ensure proper contact and measurement precision.

Q: What are the benefits of using replica tape over electronic gauges?

A: Replica tape offers direct physical evidence of surface profile and is not affected by electronic interference or calibration errors. It is easy to transport, requires no power, and provides a visual and measurable record for quality assurance documentation.

Q: Can the tape be used in high-humidity or varied temperature environments?

A: Yes, the tape is suitable for use in conditions up to 85% relative humidity and temperatures ranging from 5C to 50C, making it adaptable for diverse job sites in India and beyond.
